Product Details:
Payment & Shipping Terms:
|
| Material For The Blades: | High Speed Steel | Max PCB Cutting Length: | 460 Mm |
|---|---|---|---|
| Certificate: | CE | Shipping Way: | Option |
| Warranty: | Free For One Year | Power: | 110V / 220 V |
| Highlight: | PCB depanelization machine,V-CUT scoring machine |
||
Four Optional Speed Automatic Pcb Depanelizer For Pcb 460mm / Can Customize Length CWV-1A460
pcb separator specification :
| Pcb Separation Machine size | 77*51*45CM |
| Max. pcb cutting length | 460mm |
| cutting speed | 100/200/300/500mm/s |
| cutting thickness | 0.6-3.5mm |
| Pcb Separation Machine weight | 90 kg |
Pcb separator features :
With no banding stress design idea to operate V-Cut PCB separated process.
Lay down PC board. Rotary movement blade, Separated PCB without stress.
Cutting process is adjustable in stage.
PC board separated very fast, Operated with D.C. motor without carbon brush.
The cutting force is stably.
The speed of blade is adjustable Line with the V-cut flute and apart PC board.
Round blade and long knife bottom side could be adjust slightly.
The blade and knife could be re-sharpened, Special design for odd type component across the cutting flute is available suitable for separate long and short size PC board.
Precision and durable mechanism.
Why choose us
|
1.Engineers available to service machinery oversea. |
Engineers are available to be sent to freign countries to do machinery training and offer technical support. |
|
2.Mature technique & forerunner to process makes high quality machinery. |
As largest manufactory in South China, we have 12 years experience on PCB separator machines and soldering machines. pcb router machine Our R&D team continuously upgrade the existing machines to meet the market development trend. |
|
3.Effective customer service. pcb router machine |
All of us together are stronger and wiser than any one of us individually. To succeed, we must assume responsibility, cooperate with fellow associates and withdepartments, effectively comminicate with one another, foster enthusiam and participate in decision-making. To be seay reachable by customers and provide prompt replies to solve their problems and create value for customers. |
|
4.One year warranty for the machines except accessories. b router machine |
Robust frame construction and Japanese steel blades obtained good appraise and recognized by and oversea clients. We offer parts for replacement under warranty free of charge, clients only need to bear freight charge. |
|
Our mission: |
Ongoing PCB industry PCB separator technological innovation, to create greater value, allowing customers to success |
|
Our Vision: |
PCB industry to become the world's leading solution providers PCB separator. pcb router machine |
CE certification
