| Workstation PCB Loading/unloading: | Manual | PCB Thickness: | 0.3-3.5mm |
|---|---|---|---|
| Prodcut Name: | Printed Circuit Board Router | Program Edit: | Inline,offline |
| Workstation PCB Fixation: | Standard,specialization | Workstation PCB Thick (max): | 5mm |
| Feature: | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Poi | Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Highlight: | Inline PCB Depaneling Machine,offline PCB Depaneling Machine,110mm Height PCB Depaneling Machine |
||
PCB Depaneling Machine is a specialized machine used to separate components from a printed circuit board (PCB) by routing three milling points with a routing bit. It features a cutting speed of up to 80mm/s, a manipulator axis working area with a maximum dimension of 830mm * 580mm * 50mm, and a manipulator positioning repeatability of 0.001mm. This machine also has a routing bit life time checking and alarm system to remind the operator to change the routing bit after it has finished cutting 120m. The routing bit first 2mm cut the first milling point, middle 2mm cut the second milling point, and last 2mm cut the third milling point to increase its life time. Manual loading/unloading of PCBs is supported in the workstation. PCB Depaneling Router is an efficient tool to help achieve precise and accurate depaneling of printed circuit boards.
| Parameter Name | Parameter Value |
|---|---|
| PCB Thickness | 0.3-3.5mm |
| Positioning Accuracy | 0.01mm |
| Overall Weight | 650KG |
| Manipulator Motor type | JiaBao Series |
| Name | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Product Name | Printed Circuit Board Router |
| Overall Height offset | 60~110mm |
| Manipulator Positioning repeatability | 0.001mm |
| cutting Precision | 0.1mm |
| Workstation PCB thick (max) | 5mm |
ChuangWei PCB Depaneling Machine is made in China and certified by CE. With positioning accuracy of 0.01mm and cutting precision of 0.1mm, ChuangWei PCB Depaneling Router is perfect for PCB depaneling and CNC routing. It can cut in line, arc, circular and U-curve. The power is 2.0KW AC380V and the overall weight is 650KG. The minimum order quantity is 1 set and the delivery time is 7 days. The price is negotiable and the packing details are plywood case. The supply ability is 20 sets per month and the payment terms are T/T.
ChuangWei PCB Depaneling Router Machine is widely applied in many industries, especially for the electronics production line. It is an ideal tool for PCB depaneling and CNC routing. It can quickly and accurately complete the process of PCB depaneling and CNC routing. It can be used to cut various shapes and sizes of PCB boards. ChuangWei PCB Depaneling Router Machine can improve the efficiency of the production line and reduce the cost of the production line. It is reliable, durable and easy to operate.
ChuangWei PCB Depaneling Router Machine is perfect for PCB depaneling and CNC routing with its high precision, stability and reliability. It is widely used in the electronics industry for PCB depaneling and CNC routing. It is perfect for large-scale production and provides high quality and stable products. It is an ideal tool for PCB depaneling and CNC routing. It can quickly and accurately complete the process of PCB depaneling and CNC routing. It is the perfect solution for PCB depaneling and CNC routing.
We provide PCB Depaneling Machine, also known as PCB Depaneling Router, PCB CNC Router, with CE certification. Our PCB Depaneling Machine has the following features:
